Waterproof IP65 Solar Wall Lamp 3W for Garden , Garage Outdoor
Applications
Product Parameters:
| Parameters |
| Item No.: | SWP-3W | SWP-6W | SWP-8W |
| Maximum output power: | 3.5W | 6.8W | 8.1W |
| Working voltage | 3.2V | 3.2V | 3.2V |
| Working current | 800MA | 1800mA | 2200mA |
| Solar Panel: | 5.0V/1.5W | 5.0V/3.2W | 5.0V/4.2W |
| Battery Capacy: | 3.2V/1500MAH | 3.2V/3000MAH | 3.2V/3000MAH |
| Fully charging Time: | 6-8 hours | 6-8 hours | 6-8 hours |
| Light Sources: | 24 pcs SMD2835 | 48 pcs SMD2835 | 60 pcs SMD2835 |
| Lamp luminous flux: | 450LM | 900LM | 1100LM |
| CCT: | 2800K-3200K 4000K-4500K 6000K-6500K | 2800K-3200K 4000K-4500K 6000K-6500K | 2800K-3200K 4000K-4500K 6000K-6500K |
| Lighting Area Range: | <30㎡ | <50㎡ | <60㎡ |
| Detection Range | >180° / 5-10meter | >180° / 5-10meter | >180° / 5-10meter |
| Materials: | Alum.+ PC | Alum.+ PC | Alum.+ PC |
| Product Size: | 115*85*123mm | 240*108*85mm | 315*105*85mm |
| Working Temp.: | -10°~ +60° | -10°~ +60° | -10°~ +60° |
| Working Time(Mircro Wave Sensor Option): | 500 times(15 seconds per time) | 500 times(15 seconds per time) | 500 times(15 seconds per time) |
| Packing: | 48 PCS/ 48.5*32.5*37CM /17kgs/CTN | 24 PCS /48.5*32.5*37CM/17kgs/CTN | 15 PCS /50.5*42.5*27CM /14kgs/CTN |
Advantages:
1. ISO9001:2008
2. Free sample can be supplied as requested.
3. Small order can be suppied.
4. Quick delivery time.
LED Chip
Adopt Epistar/Brigelux led chip, large diameter double core to let
big current going through, stable working, super brightness, low
light fades and long lifespan.
Power Suppiler
Adopt isolated constant current driver with wide working voltage
85-265V,stable working and safety, used imported components, better
in quality, longer lifespan.
Installation Steps:
Applications:
1. Mainly used for road, parking lot, stores, roof, expressway,
subway, building.
2. Road toll booth decoration lighting, garden lighting and
square,.
3. at the same time can also be used in street lamps, suitable for
tunnel lighting.
And so on.
